Home > Products > Stainless Steel > Stainless Steel Pipe/Tube > A312 TP304 Seamless Stainless Steel Pipe
A312 TP304 Seamless Stainless Steel Pipe
Stainless Steel Pipe & Tube
| Product Type | Stainless Steel Pipe & Tube |
|
Outer Diamete |
6-2500mm， (3/8"-100") (Can be Customized) |
| Thickness | 0.3-150mm，(SCH10-XXS) (Can be Customized) |
| Length | 2000mm, 2500mm, 3000mm, 5800mm, 6000mm,12000mm， etc. (Can be Customized) |
| SurfaceFinish | BA, 2B, 2D, 4K, 6K, 8K, NO.1, NO.4, HL, Embossed |
| Shape | round, square and other shapes (Can be Customized) |
| Technique |
Hot Rolled / Cold Rolled/ Cold Drawn/ Thermal Expansion ERW/ LSAW/ SSAW |
| Processing Type | Cutting, bending, stamping, welding, CNC machining |
| Cutting Type | Laser cutting; water-jet cutting; flame cutting |
| Certification | ISO, SGS，BV |
| Standard | GB JIS ASTM ASME EN |
| Grade (ASTM UNS) |
200 series: 201, 202, 202cu, 204 300 series: 301, 302, 303, 304, 304L, 309, 309S, 310, 310s, 316, 316L, 316Ti, 317L, 321, 347, 347H 400 series: 409, 409L, 410, 410S, 420, 430, 431, 439, 440, 441, 444 Others: 2205,2507,2906,330,660 630 631,17-4ph,17-7ph, S318039, 904L.etc S32205，2507，254SMOS，32760，253MA，N08926 Duplex stainless steel: S22053, S25073, S22253, S31803, S32205, S32304 |
| Grade (EN) |
1.4301，1.4307，1.4541，1.4401，1.4404，1.4571，1.4438，1.4539，1.4547， 1.4529，1.4562，1.4410，1.4878，1.4845，1.4828，1.4876，2.4858，2.4819 |
| Application |
It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture, and ship components. It also applies to food and beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen mesh etc |
|
Couldn’t find steel grades you need? Please feel free to send product details to us. We would offer you a free quote as soon as possible.
|
|
| Annual Production | 800,000 tons per year |
| Main market | Aisa/ Europe/ South America/ the Middle East/ Africa |
| Service | OEM, customized processing service, customized fabrication by drawings |
| Protection |
1. Inter paper available 2. PVC protecting film available |
| Packaging & Delivery |
In bundle, plastic bags, thin film, wooden pallet, standard seaworthy export packing or as customer demands
20ftGP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM 40ftGP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ftHC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM |
ASTM A312 TP304 stainless steel chemical composition
| Grade | C | Mn | P | S | Si | Ni | Cr | Fe |
|---|---|---|---|---|---|---|---|---|
| TP304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.0 | 8-11 | 18-20 | Bal. |
ASTM A312 TP304 stainless steel mechanical properties
| Tensile Strength(Mpa) Max | Yield Point(Mpa) Max | Elongation(%) | Hardness (HRB) Max | |
|---|---|---|---|---|
| TP304 | 515 | 205 | 35 | 92 |
Dimensions Of ASTM A312 Seamless Stainless Steel Pipe
| NPS Designator | Outside Diameter | Nominal Wall Thickness | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| In. | Mm | Schedule 5S | Schedule 10S | Schedule 40S | Schedule 80S | |||||
| In. | Mm | In. | Mm | In. | Mm | In. | Mm | |||
| 1⁄8 | 0.405 | 10.29 | … | … | 0.049 | 1.24 | 0.068 | 1.73 | 0.095 | 2.41 |
| 1⁄4 | 0.540 | 13.72 | … | … | 0.065 | 1.65 | 0.088 | 2.24 | 0.119 | 3.02 |
| 3⁄8 | 0.675 | 17.15 | … | … | 0.065 | 1.65 | 0.091 | 2.31 | 0.126 | 3.20 |
| 1⁄2 | 0.840 | 21.34 | 0.065 | 1.65 | 0.083 | 2.11 | 0.109 | 2.77 | 0.147 | 3.73 |
| 3⁄4 | 1.050 | 26.67 | 0.065 | 1.65 | 0.083 | 2.11 | 0.113 | 2.87 | 0.154 | 3.91 |
| 1.0 | 1.315 | 33.40 | 0.065 | 1.65 | 0.109 | 2.77 | 0.133 | 3.38 | 0.179 | 4.55 |
| 1-1⁄4 | 1.660 | 42.16 | 0.065 | 1.65 | 0.109 | 2.77 | 0.140 | 3.56 | 0.191 | 4.85 |
| 11⁄2 | 1.900 | 48.26 | 0.065 | 1.65 | 0.109 | 2.77 | 0.145 | 3.68 | 0.200 | 5.08 |
| 2 | 2.375 | 60.33 | 0.065 | 1.65 | 0.109 | 2.77 | 0.154 | 3.91 | 0.218 | 5.54 |
| 2-1⁄2 | 2.875 | 73.03 | 0.083 | 2.11 | 0.120 | 3.05 | 0.203 | 5.16 | 0.276 | 7.01 |
| 3 | 3.500 | 88.90 | 0.083 | 2.11 | 0.120 | 3.05 | 0.216 | 5.49 | 0.300 | 7.62 |
| 3-1⁄2 | 4.000 | 101.60 | 0.083 | 2.11 | 0.120 | 3.05 | 0.226 | 5.74 | 0.318 | 8.08 |
| 4 | 4.500 | 114.30 | 0.083 | 2.11 | 0.120 | 3.05 | 0.237 | 6.02 | 0.337 | 8.56 |
| 5 | 5.563 | 141.30 | 0.109 | 2.77 | 0.134 | 3.40 | 0.258 | 6.55 | 0.375 | 9.52 |
| 6 | 6.625 | 168.28 | 0.109 | 2.77 | 0.134 | 3.40 | 0.280 | 7.11 | 0.432 | 10.97 |
| 8 | 8.625 | 219.08 | 0.109 | 2.77 | 0.148 | 3.76 | 0.322 | 8.18 | 0.500 | 12.70 |
| 10 | 10.750 | 273.05 | 0.134 | 3.40 | 0.165 | 4.19 | 0.365 | 9.27 | 0.500 | 12.70 |
| 12 | 12.750 | 323.85 | 0.156 | 3.96 | 0.180 | 4.57 | 0.375 | 9.52 | 0.500 | 12.70 |
| 14 | 14.000 | 355.60 | 0.156 | 3.96 | 0.188 | 4.78 | … | … | … | … |
| 16 | 16.000 | 406.40 | 0.165 | 4.19 | 0.188 | 4.78 | … | … | … | … |
| 18 | 18.000 | 457.20 | 0.165 | 4.19 | 0.188 | 4.78 | … | … | … | … |
| 20 | 20.000 | 508.00 | 0.188 | 4.78 | 0.218 | 5.54 | … | … | … | … |
| 22 | 22.000 | 558.80 | 0.188 | 4.78 | 0.218 | 5.54 | … | … | … | … |
| 24 | 24.000 | 609.60 | 0.218 | 5.54 | 0.250 | 6.35 | … | … | … | … |
| 30 | 30.000 | 762.00 | 0.250 | 6.35 | 0.312 | 7.92 | … | … | … | … |
Company Profile
Established 2010, JiangSu Tisco Steel has achieved a high level of knowhow and ranks among the Chinese market leaders in its business segment.
Market demand for custom-tailored products is continuously rising and JiangSu Tisco Steel adapts to these market requests by investing in innovative manufacturing technologies and increase factory production capacity.
In close co-operation with our customers, we improve performance of existing products, search for new product solutions and optimize manufacturing processes, through which we trust JiangSu Tisco Steel could provide clients with the most cost effective solution and at the same time the highest quality standard.
Product Show of Stainless Steel Pipe & Tube
FAQ
Q: Are you a manufacturer or a trading company?
A: We are both a trading company and a manufacturer.We have own factory, which is located in Jiangsu,CHINA. We have more than 10 years experience in sales of steel products. We mainly produces stainless steel plate/pipe/coil/round bars etc.
Q: Do you have quality control? How can you give warranty of your products?
A: Yes, we have gained certification of GB/T19001:2016/ ISO9001:2015. We are the verified supplier by SGS on the platform of Alibaba and MIC. We extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.
Q: How can I believe you?
A: Honest business with competitive price and professional service is our promise to all customers. We can process the order details on Alibaba platform.There is trade assurance from Alibaba, your order and money will be well guaranteed.
Q: Can we get some samples firstly?Any charges?
A: Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.
Q: How about the delivery time?
A: Normally it is 5-7 days if we have stock. If we don't have stock products,it will take 15-45 days to produce it. It is negotiable according your order quantity.
