ASTM A335 Gr./P11 Alloy Steel Pipe

ASTM A335 P11 Pipe (ASME SA335 P11) is Chrome Moly Alloy Seamless Pipe that used for high-temperature services, P11 Grade Pipe Chrome content at 1.00% to 1.50%, Moly content 0.44% to 0.65%, Minimum tensile strength 415MPa, minimum yield strength 205Mpa.

Message Email

Product Details

ASTM A335 Gr./P11 Alloy Steel Pipe

Specifications	Wall thickness	1mm~120mm
	Outside diameter	6mm~2500mm
	Length	5.8m, 6m, 11.8m, 12m, or as required.
Surface		Black painted, PE coated, HDPE, Varnished,

Seamless Ferritic and austenitic alloy tubes for boilers, superheaters and heat exchangers	ASME SA-213/SA-213M	T2,T5,T11,T12,T22,T91
Seamless Ferritic Alloy Steel nominal pipe for high temperature service	ASME SA-335/SA-335M	P2,P5,P11,P12,P22,P36,P9,P91,P92

Chemical composition:

Grade	C	Mn	Si	Mo	Cr	P	S
ASTM A335 Gr./P11	0.05-0.15	0.30-0.60	0.50-0.10	0.44-0.65	1.00-1.50	0.025	0.025

Mechanical properties：

Brand	Tensile strength (MPA)kg/mm²	Yield strength (MPA)kg/mm²	Elongation δ (%)
ASTM A335 Gr./P11	≥415	≥170	≥30

Manufacturing process：

Hot rolling (extruded seamless steel pipe) : round tube billet → heating → perforation → three-roll oblique rolling, continuous rolling or extrusion → pipe stripping → sizing (or reducing) → cooling → billet → straightening → hydrostatic test (or flaw detection) → marking → storage.

Cold drawing (rolled) seamless steel tube: round tube blank → heating → perforation → heading → annealing → pickling → oiling (copper plating) → multi-pass cold drawing (cold rolling) → blank tube → heat treatment → straightening → hydrostatic test (flaw detection) → marking → storage.
